Great
main console, unenclosed
main console, unenclosed
16'
Rohrbourdon
73 pipes
8'
Principal
61 pipes
8'
Harmonic Flute
73 pipes
8'
Rohrbourdon
4'
Octave
61 pipes
4'
Harmonic Flute
2'
Fifteenth
61 pipes
IV
Fourniture
244 pipes
III
Cymbal
183 pipes
16'
Tromba
8'
Tromba
85 pipes
4'
Tromba
8'
Tuba
61 pipes
Chimes
25 tubes
Tremulant
Super, Sub, Unison Off
Swell-Great 16', 8', 4'
Choir-Great 16', 8', 4'
Antiphonal Positiv-Great 16', 8', 4'
Choir-Great transfer
Swell
main console, expressive
main console, expressive
16'
Contre Gamba
80 pipes
16'
Flûte à Cheminée
80 pipes
8'
Flûte à Cheminée
8'
Viola da Gamba
8'
Voix Celeste
56 pipes
4'
Flûte Harmonique
68 pipes
4'
Principal
68 pipes
2'
Flûte à Bec
61 pipes
2 2/3'
Nazard
61 pipes
1 3/5'
Tierce
61 pipes
IV
Plein Jeu
244 pipes
16'
Bombarde
68 pipes
8'
Trompette
68 pipes
8'
Hautbois
68 pipes
8'
Voix Humaine
68 pipes
4'
Clarion
68 pipes
8'
Tuba
Gt.
Tremulant
Super, Sub, Unison Off
Choir
main console, expressive
main console, expressive
8'
Diapason
61 pipes
8'
Dolcan
61 pipes
8'
Dolcan Celeste
49 pipes
8'
Stopped Flute
61 pipes
4'
Octave
61 pipes
2 2/3'
Twelfth
61 pipes
2'
Recorder
61 pipes
1 3/5'
Seventeenth
61 pipes
1 1/3'
Nineteenth
61 pipes
III
Scharff
138 pipes
16'
Dulcian
61 pipes
8'
Tromba
Gt.
8'
Trumpet
61 pipes
8'
Scham
61 pipes
16'
Tuba (TC)
Gt.
8'
Tuba
Gt.
4'
Tuba
Gt.
Tremulant
Super, Sub, Unison Off
Swell-Choir 16', 8', 4'
Pedal
main console, unenclosed
main console, unenclosed
32'
Untersatz
electronic
32'
Sub Bourdon
electronic
16'
Principal
61 pipes
16'
Bourdon
56 pipes
16'
Contre Gambe
Sw.
16'
Rohrbourdon
Gt.
16'
Flûte à Cheminée
Sw.
8'
Octave
32 pipes
8'
Bourdon
8'
Viola da Gamba
Sw.
8'
Spitzflute
44 pipes
8'
Rohrbourdon
(16' Bour)
8'
Flûte à Cheminée
Sw.
4'
Choral Bass
32 pipes
4'
Bourdon
4'
Spitzflute
4'
Harmonic Flute
Gt.
2'
Nachthorn
32 pipes
III
Mixture
96 pipes
32'
Contra Posaune
electronic
16'
Posaune
58 pipes
16'
Tromba
Gt.
16'
Bombarde
Sw.
8'
Posaune
8'
Tromba
Gt.
8'
Bombarde
Sw.
4'
Posaune
4'
Bombarde
Sw.
8'
Tuba
Gt.
Chimes
Gt.
Great-Pedal 8', 4'
Swell-Pedal 8', 4'
Choir-Pedal 8', 4'
Ant. Great-Pedal 8', 4'
Ant. Positiv-Pedal 8', 4'
Antiphonal Great
main & gallery consoles, unenclosed
main & gallery consoles, unenclosed
8'
Prestant
56 pipes
8'
Hohlflute
56 pipes
8'
Gemshorn
56 pipes
4'
Prinzipal
56 pipes
2'
Blockflöte
56 pipes
1 1/3'
Quint
56 pipes
II
Sesquialtera
60 pipes
8'
Krumhorn
56 pipes
Zimbelstern
Tremulant
Super, Sub, Unison Off
Antiphonal Positiv
main & gallery consoles, unenclosed
main & gallery consoles, unenclosed
8'
Holzgedeckt
56 pipes
4'
Koppelflute
56 pipes
2'
Weitprinzipal
56 pipes
1'
Sifflote
56 pipes
III
Zimbel
168 pipes
8'
Petite Trumpet
56 pipes
8'
Krumhorn
Ant. Gt.
Tremulant
Super, Sub, Unison Off
Antiphonal Pedal
main & gallery consoles, unenclosed
main & gallery consoles, unenclosed
16'
Holzgedeckt
Ant. Pos.
8'
Prestant
Ant. Gt.
8'
Holzgedeckt
Ant. Pos.
4'
Prestant
Ant. Gt.
8'
Krumhorn
Ant. Gt.
4'
Krumhorn
Ant. Gt.
- The Great Tuba, on 25" wind, is located in the former Skinner Echo expression chamber 90' above the floor at the central peak of the roof.
- Three manual main console movable in front of Chapel
- Two manual gallery console fixed in rear balcony of Chapel
- 20 general pistons, 6 division pistions per division, 6 coupler pistons
- 3 Tutti levels on pistons and studs
- 8 reversible toe studs for couplers
- Reversible toe studs for 32' stops
- Gallery organ disconnect
- MIDI In, Out, Through
